    Vishay Semiconductor Opto Division CNY17F-3

    Part No.:
    CNY17F-3
    Manufacturer:
    Vishay Semiconductor Opto Division
    Category:
    Transistor, Photovoltaic Output Optoisolators
    Package:
    6-DIP (0.300", 7.62mm)
    Datasheet:
    KATY Electronic Technology Co., LTDCNY17F-3.pdf
    Description:
    OPTOISOLTR 5KV TRANSISTOR 6-DIP
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Vishay Semiconductor Opto Division
    Series:
    -
    Package/Case:
    6-DIP (0.300", 7.62mm)
    Packaging:
    Tube
    Product Status:
    Active
    Number of Channels:
    1
    Voltage - Isolation:
    5000Vrms
    Current Transfer Ratio (Min):
    100% @ 10mA
    Current Transfer Ratio (Max):
    200% @ 10mA
    Turn On / Turn Off Time (Typ):
    3µs, 2.3µs
    Rise / Fall Time (Typ):
    2µs, 2µs
    Input Type:
    DC
    Output Type:
    Transistor
    Voltage - Output (Max):
    70V
    Current - Output / Channel:
    50mA
    Voltage - Forward (Vf) (Typ):
    1.39V
    Current - DC Forward (If) (Max):
    60 mA
    Vce Saturation (Max):
    400mV
    Grade:
    -
    Qualification:
    -
    Operating Temperature:
    -55°C ~ 110°C
    Mounting Type:
    Through Hole
    Supplier Device Package:
    6-DIP
