    Triad Magnetics VPT12-13300

    Part No.:
    VPT12-13300
    Manufacturer:
    Triad Magnetics
    Category:
    Power Transformers
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTDVPT12-13300.pdf
    Description:
    PWR XFMR TOROIDAL 160VA CHAS MT
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Triad Magnetics
    Series:
    Chassis Mount: World Series™
    Packaging:
    Box
    Product Status:
    Active
    Type:
    Toroidal
    Voltage - Primary:
    115V, 230V
    Voltage - Secondary (Full Load):
    Parallel 6V, Series 12V
    Current - Output (Max):
    Parallel 26.6A, Series 13.3A
    Primary Winding(s):
    Dual
    Secondary Winding(s):
    Dual
    Center Tap:
    No
    Power - Max:
    160VA
    Mounting Type:
    Chassis Mount
    Termination Style:
    Wire Leads
    Size / Dimension:
    103.00mm Dia x 48.00mm W
    Height - Seated (Max):
    52.0mm
    Voltage - Isolation:
    4000Vrms
    Weight:
    3.6 lbs (1.6 kg)
