    Taiwan Semiconductor Corporation RS1M

    Part No.:
    RS1M
    Manufacturer:
    Taiwan Semiconductor Corporation
    Category:
    Single Diodes
    Package:
    DO-214AC, SMA
    Datasheet:
    KATY Electronic Technology Co., LTDRS1M.pdf
    Description:
    DIODE GEN PURP 1A DO214AC
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Taiwan Semiconductor Corporation
    Series:
    -
    Package/Case:
    DO-214AC, SMA
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    Technology:
    Standard
    Voltage - DC Reverse (Vr) (Max):
    1000 V
    Current - Average Rectified (Io):
    1A
    Voltage - Forward (Vf) (Max) @ If:
    1.3 V @ 1 A
    Speed:
    Fast Recovery =< 500ns, > 200mA (Io)
    Reverse Recovery Time (trr):
    500 ns
    Current - Reverse Leakage @ Vr:
    5 µA @ 1000 V
    Capacitance @ Vr, F:
    10pF @ 4V, 1MHz
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    DO-214AC (SMA)
    Operating Temperature - Junction:
    -55°C ~ 150°C
