STMicroelectronics STL6N2VH5

Name: STL6N2VH5
Brand: STMicroelectronics
SKU: STL6N2VH5
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: STL6N2VH5

Manufacturer:: STMicroelectronics

Category:: FETs, MOSFETs

Package:: 6-PowerWDFN

Datasheet:: STL6N2VH5.pdf

Description:: MOSFET N-CH 20V POWERFLAT

Quantity:: RFQ Add To RFQ list

Payment:

Shipping:

Product details

Specifications
FAQ
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: STMicroelectronics

Series:: STripFET™ V

Package/Case:: 6-PowerWDFN

Packaging:: Tape & Reel (TR)

Product Status:: Active

FET Type:: N-Channel

Technology:: MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss):: 20 V

Current - Continuous Drain (Id) @ 25°C:: 6A (Tj)

Drive Voltage (Max Rds On, Min Rds On):: 2.5V, 4.5V

Rds On (Max) @ Id, Vgs:: 30mOhm @ 3A, 4.5V

Vgs(th) (Max) @ Id:: 700mV @ 250µA (Min)

Gate Charge (Qg) (Max) @ Vgs:: 6 nC @ 4.5 V

Vgs (Max):: ±8V

Input Capacitance (Ciss) (Max) @ Vds:: 550 pF @ 16 V

FET Feature:: -

Power Dissipation (Max):: 2.4W (Tc)

Operating Temperature:: -55°C ~ 150°C (TJ)

Grade:: -

Qualification:: -

Mounting Type:: Surface Mount

Supplier Device Package:: PowerFlat™ (2x2)
