    Signal Transformer 36-8

    Part No.:
    36-8
    Manufacturer:
    Signal Transformer
    Category:
    Power Transformers
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTD36-8.pdf
    Description:
    PWR XFMR LAMINATED 288VA CHAS MT
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Signal Transformer
    Series:
    -
    Packaging:
    Box
    Product Status:
    Active
    Type:
    Laminated Core
    Voltage - Primary:
    105V, 115V, 125V
    Voltage - Secondary (Full Load):
    Parallel 18V, Series 36V
    Current - Output (Max):
    Parallel 16A, Series 8A
    Primary Winding(s):
    Single, Multiple Taps
    Secondary Winding(s):
    Dual
    Center Tap:
    Yes
    Power - Max:
    288VA
    Mounting Type:
    Chassis Mount
    Termination Style:
    Solder, Quick Connect
    Size / Dimension:
    114.30mm L x 114.30mm W
    Height - Seated (Max):
    95.30mm
    Voltage - Isolation:
    1500Vrms
    Weight:
    11 lbs (5 kg)
