    Panasonic Electronic Components EVP-AWCD4A

    Part No.:
    EVP-AWCD4A
    Manufacturer:
    Panasonic Electronic Components
    Category:
    Tactile Switches
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTDEVP-AWCD4A.pdf
    Description:
    SWITCH TACTILE SPST-NO 0.02A 15V
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Panasonic Electronic Components
    Series:
    EVPAW
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    Circuit:
    SPST-NO
    Switch Function:
    Off-Mom
    Contact Rating @ Voltage:
    0.02A @ 15VDC
    Actuator Type:
    Standard
    Mounting Type:
    Surface Mount
    Actuator Height off PCB, Vertical:
    0.60mm
    Actuator Length, Right Angle:
    -
    Actuator Orientation:
    Top Actuated
    Termination Style:
    SMD (SMT) Tab
    Outline:
    3.00mm x 2.00mm
    Illumination:
    Non-Illuminated
    Illumination Type, Color:
    -
    Illumination Voltage (Nominal):
    -
    Operating Force:
    240gf
    Ingress Protection:
    IP67 - Dust Tight, Waterproof
    Features:
    -
    Operating Temperature:
    -40°C ~ 85°C
