    OptiFuse RS120-110

    Part No.:
    RS120-110
    Manufacturer:
    OptiFuse
    Category:
    PTC Resettable Fuses
    Package:
    Radial, Disc
    Datasheet:
    KATY Electronic Technology Co., LTDRS120-110.pdf
    Description:
    PTC RESET FUSE 120V 1.1A RADIAL
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    OptiFuse
    Package/Case:
    Radial, Disc
    Series:
    RS120
    Packaging:
    Bulk
    Product Status:
    Active
    Type:
    Polymeric
    Voltage - Max:
    120V (135V Int)
    Current - Hold (Ih) (Max):
    1.1 A
    Current - Trip (It):
    2.2 A
    Current - Max:
    8 A
    Time to Trip:
    8.2 s
    Resistance - Initial (Ri) (Min):
    150 mOhms
    Resistance - Post Trip (R1) (Max):
    380 mOhms
    Resistance - 25°C (Typ):
    -
    Operating Temperature:
    -40°C ~ 85°C
    Grade:
    -
    Qualification:
    -
    Ratings:
    -
    Mounting Type:
    Through Hole
    Size / Dimension:
    0.524" Dia x 0.161" T (13.30mm x 4.10mm)
    Height - Seated (Max):
    0.720" (18.30mm)
    Thickness (Max):
    -
    Lead Spacing:
    0.201" (5.10mm)
