    iNRCORE, LLC Q1553-20

    Part No.:
    Q1553-20
    Manufacturer:
    iNRCORE, LLC
    Category:
    Pulse Transformers
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTDQ1553-20.pdf
    Description:
    TRANSFORMER PBC
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    iNRCORE, LLC
    Series:
    -
    Packaging:
    Tube
    Product Status:
    Active
    Transformer Type:
    MIL-STD-1553
    Inductance:
    -
    ET (Volt-Time):
    -
    Turns Ratio - Primary:Secondary:
    1:1.41
    Mounting Type:
    Through Hole
    Size / Dimension:
    0.500" L x 0.350" W (12.70mm x 8.89mm)
    Height - Seated (Max):
    0.250" (6.35mm)
    Operating Temperature:
    -
    Grade:
    -
    Qualification:
    -
