    Hammond Manufacturing 149C

    Part No.:
    149C
    Manufacturer:
    Hammond Manufacturing
    Category:
    Audio Transformers
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTD149C.pdf
    Description:
    AUDIO XFMR 160 / 80, 20/20 TH
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Hammond Manufacturing
    Series:
    149
    Packaging:
    Bulk
    Product Status:
    Active
    Turns Ratio - Primary:Secondary:
    -
    Impedance - Primary (Ohms):
    160
    Impedance - Secondary (Ohms):
    80, 20/20
    DC Resistance (DCR) - Primary:
    24Ohm
    DC Resistance (DCR) - Secondary:
    7Ohm
    Transformer Type:
    Economical Open Type
    Frequency Range:
    200Hz ~ 15kHz
    Frequency Response:
    ±1dB
    Voltage - Isolation:
    -
    Insertion Loss:
    0.5dB
    Return Loss:
    -
    Power Level:
    200mW
    Operating Temperature:
    -
    Approval Agency:
    -
    Mounting Type:
    Through Hole
    Size / Dimension:
    1.060" L x 0.820" W (26.92mm x 20.83mm)
    Height - Seated (Max):
    0.820" (20.83mm)
    Termination Style:
    PC Pin
