    Diodes Incorporated DMP2035UVT-13

    Part No.:
    DMP2035UVT-13
    Manufacturer:
    Diodes Incorporated
    Category:
    FETs, MOSFETs
    Package:
    SOT-23-6 Thin, TSOT-23-6
    Datasheet:
    KATY Electronic Technology Co., LTDDMP2035UVT-13.pdf
    Description:
    MOSFET P-CH 20V 7.2A TSOT26
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Diodes Incorporated
    Series:
    -
    Package/Case:
    SOT-23-6 Thin, TSOT-23-6
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Obsolete
    FET Type:
    P-Channel
    Technology:
    MOSFET (Metal Oxide)
    Drain to Source Voltage (Vdss):
    20 V
    Current - Continuous Drain (Id) @ 25°C:
    7.2A (Ta)
    Drive Voltage (Max Rds On, Min Rds On):
    1.8V, 4.5V
    Rds On (Max) @ Id, Vgs:
    35mOhm @ 4A, 4.5V
    Vgs(th) (Max) @ Id:
    1.5V @ 250µA
    Gate Charge (Qg) (Max) @ Vgs:
    23.1 nC @ 4.5 V
    Vgs (Max):
    ±12V
    Input Capacitance (Ciss) (Max) @ Vds:
    2400 pF @ 10 V
    FET Feature:
    -
    Power Dissipation (Max):
    2W (Ta)
    Operating Temperature:
    -55°C ~ 150°C (TJ)
    Grade:
    Automotive
    Qualification:
    AEC-Q101
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    TSOT-26

    1. How to order DMP2035UVT-13 on KATY Electronic Technology Co., LTD?

    Currently, KATY Electronic Technology Co., LTD only provide peer-to-peer order processing. While you submit the RFQ, our professional agent will contact you with the competitive prices in the global market, and our agent will prompt you to finish the order if you accept our offers.

    2. How does KATY Electronic Technology Co., LTD guarantee that DMP2035UVT-13 is from the original manufacturer or authorized agents?

    We have a professional and experienced quality control team to strictly verify and test the DMP2035UVT-13. All suppliers must pass our qualification reviews before they can publish their products including DMP2035UVT-13 on KATY Electronic Technology Co., LTD; we pay more attention to the channels and quality of DMP2035UVT-13 products than any other customer. We strictly implement supplier audits, so you can purchase with confidence.

    3. Are the DMP2035UVT-13 price and inventory displayed accurate?

    The price and inventory of DMP2035UVT-13 fluctuates frequently and cannot be updated in time, it will be updated periodically within 24 hours. And, our quotation usually expires after 5 days.

    4. What forms of payment are accepted?

    Wire Transfer, PayPal, Alipay, Wechat, Credit Card, Western Union, MoneyGram, and Escrow are all acceptable.

    Warm Tips: Some orders in certain payment forms may require handling fee.

    5. How is the shipping arranged?

    Customers can choose industry-leading freight companies, including DHL, UPS, FedEx, TNT, and Registered Mail. Shipping insurance is also available.

    Once your order has been processed for shipment, our salesperson will send you an email advising you of the shipping status and tracking number.

    Warm Tips: It may take up to 24 hours for the carriers to display tracking information. Usually, express delivery takes 3-5 days, and registered mail takes 25-60 days.

    6. What is the process for return or replacement of DMP2035UVT-13?

    All goods will implement Pre-Shipment Inspection (PSI), selected at random from all batches of your order to do a systematic inspection before arranging the shipment. If there is something wrong with the DMP2035UVT-13 we delivered, we will accept the replacement or return of the DMP2035UVT-13 only when all of the below conditions are fulfilled:

    (1)Such as a deficiency in quantity, delivery of wrong items, and apparent external defects (breakage and rust, etc.), and we acknowledge such problems.

    (2)We are informed of the defect described above within 90 days after the delivery of DMP2035UVT-13.

    (3)The PartNo is unused and only in the original unpacked packaging.

    Two processes to return the products:

    (1)Inform us within 90 days

    (2)Obtain Requesting Return Authorizations

    7.How to contact us to get technical supports, such as DMP2035UVT-13 pin diagram, DMP2035UVT-13 datasheet?

    If you need any after-sales service, please do not hesitate to contact us.

    Image DMP2035UVTQ-13 DMP2035UVT-13
    Part Number DMP2035UVTQ-13 DMP2035UVT-13
    Manufacturer Diodes Incorporated Diodes Incorporated
    Series - -
    Package/Case SOT-23-6 Thin, TSOT-23-6 SOT-23-6 Thin, TSOT-23-6
    Packaging Tape & Reel (TR) Tape & Reel (TR)
    Product Status Active Obsolete
    FET Type P-Channel P-Channel
    Technology MOSFET (Metal Oxide) MOSFET (Metal Oxide)
    Drain to Source Voltage (Vdss) 20 V 20 V
    Current - Continuous Drain (Id) @ 25°C 7.2A (Ta) 7.2A (Ta)
    Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V 1.8V, 4.5V
    Rds On (Max) @ Id, Vgs 35mOhm @ 4A, 4.5V 35mOhm @ 4A, 4.5V
    Vgs(th) (Max) @ Id 1.5V @ 250µA 1.5V @ 250µA
    Gate Charge (Qg) (Max) @ Vgs 23.1 nC @ 4.5 V 23.1 nC @ 4.5 V
    Vgs (Max) ±12V ±12V
    Input Capacitance (Ciss) (Max) @ Vds 2400 pF @ 10 V 2400 pF @ 10 V
    FET Feature - -
    Power Dissipation (Max) 2W (Ta) 2W (Ta)
    Operating Temperature -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ)
    Grade Automotive Automotive
    Qualification AEC-Q101 AEC-Q101
    Mounting Type Surface Mount Surface Mount
    Supplier Device Package TSOT-23-6 TSOT-26
