    CODACA CSBX0650-100M

    Part No.:
    CSBX0650-100M
    Manufacturer:
    CODACA
    Category:
    Fixed Inductors
    Package:
    Nonstandard
    Datasheet:
    KATY Electronic Technology Co., LTDCSBX0650-100M.pdf
    Description:
    SMD HIGH CURRENT POWER INDUCTOR
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    CODACA
    Series:
    CSBX0650
    Package/Case:
    Nonstandard
    Packaging:
    Cut Tape (CT)
    Product Status:
    Active
    Type:
    Wirewound
    Material - Core:
    Metal Composite
    Inductance:
    10 µH
    Tolerance:
    ±20%
    Current Rating (Amps):
    4.4 A
    Current - Saturation (Isat):
    7.4A
    Shielding:
    Shielded
    DC Resistance (DCR):
    30.5mOhm Max
    Q @ Freq:
    -
    Frequency - Self Resonant:
    -
    Ratings:
    AEC-Q200
    Operating Temperature:
    -55°C ~ 150°C
    Inductance Frequency - Test:
    100 kHz
    Features:
    High Saturation
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    -
    Size / Dimension:
    0.276" L x 0.272" W (7.00mm x 6.90mm)
    Height - Seated (Max):
    0.197" (5.00mm)
