    Amazing AZ1013-04C

    Part No.:
    AZ1013-04C
    Manufacturer:
    Amazing
    Category:
    TVS Diodes
    Package:
    5-TSSOP, SC-70-5, SOT-353
    Datasheet:
    KATY Electronic Technology Co., LTDAZ1013-04C.pdf
    Description:
    LOW CAP ESD HIGH SPEED 4-CH 3.3V
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Amazing
    Package/Case:
    5-TSSOP, SC-70-5, SOT-353
    Series:
    -
    Packaging:
    Strip
    Product Status:
    Active
    Type:
    Zener
    Unidirectional Channels:
    4
    Bidirectional Channels:
    -
    Voltage - Reverse Standoff (Typ):
    3.3V (Max)
    Voltage - Breakdown (Min):
    4.5V
    Voltage - Clamping (Max) @ Ipp:
    7.8V
    Current - Peak Pulse (10/1000µs):
    -
    Power - Peak Pulse:
    -
    Power Line Protection:
    No
    Applications:
    USB
    Capacitance @ Frequency:
    -
    Operating Temperature:
    -55°C ~ 125°C (TC)
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    SC-70-5
