    Allied Components International PCSV65-101M-RC

    Part No.:
    PCSV65-101M-RC
    Manufacturer:
    Allied Components International
    Category:
    Fixed Inductors
    Package:
    Nonstandard
    Datasheet:
    KATY Electronic Technology Co., LTDPCSV65-101M-RC.pdf
    Description:
    100H 20% SHIELDED POWER CHIP IND
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Allied Components International
    Series:
    -
    Package/Case:
    Nonstandard
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    Type:
    -
    Material - Core:
    -
    Inductance:
    100 µH
    Tolerance:
    ±20%
    Current Rating (Amps):
    800 mA
    Current - Saturation (Isat):
    1.3A
    Shielding:
    Shielded
    DC Resistance (DCR):
    500mOhm
    Q @ Freq:
    -
    Frequency - Self Resonant:
    -
    Ratings:
    -
    Operating Temperature:
    -40°C ~ 125°C
    Inductance Frequency - Test:
    100 kHz
    Features:
    -
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    -
    Size / Dimension:
    0.236" L x 0.236" W (6.00mm x 6.00mm)
    Height - Seated (Max):
    0.177" (4.50mm)
