    ZF Electronics DB1C-A1RC

    Part No.:
    DB1C-A1RC
    Manufacturer:
    ZF Electronics
    Category:
    Limit Switches
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTDDB1C-A1RC.pdf
    Description:
    SWITCH SNAP ACTION SPDT 5A 125V
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    ZF Electronics
    Series:
    DB
    Packaging:
    Bulk
    Product Status:
    Active
    Circuit:
    SPDT
    Switch Function:
    On-Mom
    Current Rating (Amps):
    5A (AC), 1A (DC)
    Voltage Rating - AC:
    125 V
    Voltage Rating - DC:
    48 V
    Actuator Type:
    Lever, Roller
    Mounting Type:
    Chassis Mount
    Termination Style:
    Solder Lug
    Ingress Protection:
    IP50 - Dust Protected
    Features:
    -
    Operating Force:
    55gf
    Release Force:
    -
    Operating Position:
    0.638" (16.2mm)
    Pretravel:
    0.178" (4.5mm)
    Differential Travel:
    0.025" (0.6mm)
    Overtravel:
    0.079" (2.0mm)
    Operating Temperature:
    -40°C ~ 120°C
