    Panasonic Electric Works HC4ED-L-DC100V

    Part No.:
    HC4ED-L-DC100V
    Manufacturer:
    Panasonic Electric Works
    Category:
    Signal Relays, Up to 2 Amps
    Package:
    Datasheet:
    KATY Electronic Technology Co., LTDHC4ED-L-DC100V.pdf
    Description:
    RELAY GEN PURPOSE 4PDT 1A 100V
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Panasonic Electric Works
    Series:
    HCE
    Packaging:
    Bulk
    Product Status:
    Obsolete
    Mounting Type:
    Socketable
    Coil Voltage:
    100VDC
    Contact Form:
    4PDT (4 Form C)
    Contact Rating (Current):
    1 A
    Switching Voltage:
    250VAC - Max
    Load - Max Switching:
    250VA
    Coil Current:
    11 mA
    Coil Type:
    Non Latching
    Features:
    Lighted Indicator
    Termination Style:
    Plug In
    Seal Rating:
    -
    Coil Insulation:
    -
    Must Operate Voltage:
    80 VDC
    Must Release Voltage:
    10 VDC
    Operate Time:
    20 ms
    Release Time:
    20 ms
    Operating Temperature:
    -40°C ~ 60°C
    Contact Material:
    Silver Nickel (AgNi), Gold (Au)
    Relay Type:
    General Purpose
    Grade:
    -
    Qualification:
    -
