    Eaton - Electronics Division CTX0.33-1A-R

    Part No.:
    CTX0.33-1A-R
    Manufacturer:
    Eaton - Electronics Division
    Category:
    Arrays, Signal Transformers
    Package:
    Nonstandard
    Datasheet:
    KATY Electronic Technology Co., LTDCTX0.33-1A-R.pdf
    Description:
    INDUCT ARRAY 2 COIL 402NH SMD
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Eaton - Electronics Division
    Series:
    OCTA-PAC® PLUS
    Package/Case:
    Nonstandard
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Obsolete
    Number of Coils:
    2
    Inductance - Connected In Parallel:
    402 nH
    Inductance - Connected In Series:
    1.61 µH
    Tolerance:
    ±25%
    Current Rating - Parallel:
    10 A
    Current Rating - Series:
    4.98 A
    Current Saturation - Parallel:
    12.5 A
    Current Saturation - Series:
    6.25 A
    DC Resistance (DCR) - Parallel:
    3.7mOhm Max
    DC Resistance (DCR) - Series:
    15mOhm Max
    Shielding:
    Unshielded
    Ratings:
    -
    Operating Temperature:
    -40°C ~ 85°C
    Mounting Type:
    Surface Mount
    Size / Dimension:
    0.450" L x 0.450" W (11.43mm x 11.43mm)
    Height:
    0.165" (4.19mm)
